Researchers working to shrink AR tech to fit inside standard eye glasses

Researchers working to shrink AR tech to fit inside standard eye glasses
A researc report in ACS Photonics has explored the concept of how to combine two optical technologies into a single, high-resolution AR display. In an eyeglasses prototype, the researchers enhanced image quality with a computer algorithm that removed distortions.

AR systems, like those in bulky goggles and automobile head-up displays, require portable optical components. But shrinking the typical four-lens AR system to the size of eyeglasses or smaller typically lowers the quality of the computer-generated image and reduces the field of view.

Youguang Ma and colleagues may have found a solution for condensing the technology. They combined two optical technologies — a metasurface and a refractive lens — with a microLED screen (containing arrays of tiny green LEDs for projecting images) to create a compact, single-lens hybrid AR design.

A new, simpler AR display incorporated into eyeglasses takes an original image (top) and produces a projected image (middle) that is further enhanced by a computer algorithm (bottom).

image credit: Adapted from ACS Photonics 2024, DOI: 10.1021/acsphotonics.4c00989

Their display’s metasurface is an ultrathin, lightweight silicon nitride film etched with a pattern. The pattern shapes and focuses light from the green microLEDs. Then, a black-and-green image forms on a refractive lens made from a synthetic polymer, which refines the image by sharpening and reducing aberrations in the light. The final image is projected out of the system and superimposed onto an object or screen. To further enhance the resolution of the projected image, Ma and the team used computer algorithms to identify minor imperfections in the optical system and correct them before light leaves the microLED.

The researchers integrated the hybrid AR display into a pair of eyeglasses and tested the prototype’s performance with computer image enhancement. Projected images from the one-lens hybrid system had less than 2% distortion across a 30° field of view — image quality that’s on par with current commercial AR platforms with four lenses. The researchers then confirmed that their computer preprocessing algorithm improved a reprojected AR picture of a red panda. The reprojected red panda was 74.3% structurally similar to the original image — a 4% improvement from the uncorrected projection of the image. With additional development, the researchers say the platform could extend from green to full colour and enable a new generation of mainstream AR glasses.
